Features

- Transport width all models add 875mm to working width
- Equal side loading on all gang bearings
- Gang angles independently adjustable
- Roll out gangs
- 9 spacings
- Hangers of slim design pressed from hi-tensile steel
- Discs spacers reduced diameter 4 more disc
wear with increased soil and trash flow
- Twist out bearings
- Suits Cat 4, Cat 4 Narrow & Cat 3 Tractor hitches with minimal effort required for fitment.
- Central rod assembly that allows dynamic loads to be placed to the rear of the tractor for more traction.

Technical Details

Discs: 28 x 8mm Scalloped
Gang Bolts: 2 diameter all models
Bearings: Protected greasable gang bearings with triple lip seal
Main Frame: 150 x 100 x 9mm RHS
Plough Weight: Approx 3500Kg (32 Plate)
