Technical Details

Discs: Front 28 x 8 mm all round/optinal 30
Tyres: 305 x 19.5 Super Single truck tyres Up to 76 plate 80-92 plate super single truck tyres or aircraft tyres

Gang Bolts: 2 diameter all model (H/T)
Bearings: Protected greasable gang bearings with triple lip seals
Main Frame: 200 x 100 x 9mm RHS, Laminated with 20mm plate
Disc Weight: Approx 190 to 205kg per disc
Stub Axles 6 stud 75mm up to 76 plate - 90 Ø stud 80-92 plate


Other Features

- Gang angles independently adjustable
- Equal side loading on all gang bearings
- 9 spacings
- Roll out gangs
- Hydraulic levelling cylinder
- Bearing hangers of slim design
- Discs spacers reduced diameter 4 more disc wear with increased soil and trash flow
- Pressed from hi - tensile steel
- Bolted stub axles with triple lip seals and dust covers

Options

- Walking wheels on centre frame 84-92 plate
- Aircraft tyres + 90mm axles - 8 stud
- Large 219mm spools for heavy applications
